6 - USE AND OPERATION MASTER 880MP E-volution
GB
6 - Pag. 13 / 17
6.8 BAR LOADING - PROCEDURE
Initial status:
- the “AUTOMATIC signal FROM LATHE” and “OPEN COLLET”
- the bar feeder must be set on its “MANUAL” function
Press
(phase “ BAR PUSHER
RETURN AFTER REMNANT
DROP ”)
Press and to
select the
“SEMIAUTOMATIC” function
Press
(phase “BAR PUSHER
RETURN”)
Press
(phase “ CLAMP
CLOSING ”)
Press
(phase “ DROP REMNANT
REMOVAL ”)
Press
(phase “ CLAMP OPENING
AFTER REMOVAL ”)
Press
(phase “ REMNANT DROP
FEEDING ”)
Press
(phase “ CLAMP CLOSING
DROP CONTROL ”)
Press
(phase “ CLAMP OPENING
AFTER DROP CONTROL ”)
Press
(phase “ZERO AXIS”)
Press
(phase “ GUIDE FULL
OPENING ”)
“SEMIAUTOMATIC”
Procedure
“MANUAL”
Procedure
