2.9 ADJUST THE MEDIA WIDTH
The media width adjustment dial allows you to adjust the pressure of the
thermal head according to the media width. The default factory setting value
is 6. This setting is suitable for standard ATB and Bag Tag media.
Below process applies for nonstandard media.
1. Rotate the media width adjustment dial until you reach the desired
setting.
Dial
Media width (mm)
Media width (in)
0
19.5 to 23.0
0.77 to 0.90
1
23.0 to 30.0
0.90 to 1.18
2
30.0 to 39.0
1.18 to 1.53
3
39.0 to 49.0
1.53 to 1.92
4*
49.0 to 62.0
1.92 to 2.44
5
62.0 to 76.0
2.44 to 2.99
6**
76.0 to 88.0
2.99 to 3.46
7
88.0 to 99.0
3.46 to 3.89
8
99.0 to 108
3.89 to 4.25
9
108 to 118
4.25 to 4.65
(*) suitable for bag tag media
(**) suitable for ATB and bag tag media (factory setting)
2. Do a print test (see page 18).
3. If the printing is brighter to the right than to the left, increase the setting
value.
