IFM Efector500 PY7102 - 11�1 Setting Ranges; Factory Preset

16
11.1 Setting ranges
SP1 rP1
ΔP
min max min max
PY7102
MPa 0�06 10�00 0�04 9�96 0�02
bar 0�6 100�0 0�4 99�6 0�2
PSI 12 1450 8 1440 4
ΔP=increments
12 Factory preset
Factory preset User setting
SP1 3.50
rP1 3.46
OU1 Hno
OU2 Hno
SP2 0.10
rP2 0.08
dS1 0.0
dr1 0.0
dS2 0.0
dr2 0.0
P-n nPn
dAP 60
diS d2
Uni MPA
