7.2 Menu explanation
SP1/rP1 Upper / lower limit value for the system pressure at which output 1 changes
its switching status�
SP2/rP2 Upper / lower limit value for the system pressure at which output 2 changes
its switching status�
OU1 Output function for OUT1:
Switching signal for the limit values: hysteresis function [H ��] or window •
function [F ��], normally open [� no] or normally closed [� nc] each�
OU2 Output function for OUT2:
Switching signal for the limit values: hysteresis function [H ��] or window •
function [F ��], normally open [� no] or normally closed [� nc] each�
Diagnostic signal, [OU2] = [dESI]�•
EF Extended functions / Opening menu level 2�
Uni Standard unit of measurement for the system pressure�
HI Maximum value memory for the system pressure�
dS1 / dS2 Switch-ondelay/resetdelayforOUT1/OUT2.
dr1/dr2 Reset delay for OUT1 / OUT2
P-n Output polarity�
dAP Damping for the switching outputs
diS Update rate and orientation of the display�
