8.3.3 Setting the delay time for the switching outputs
[dS1]/[dS2]=switch-ondelayforOUT1/OUT2. ►
[dr1]/[dr2]=switch-offdelayforOUT1/OUT2 ►
Select [dS1], [dS2], [dr1] or [dr2] set value between 0�1 und 50 s (at 0�0 ►
the delay time is not active)�
8.3.4 Setting the damping for the switching outputs
Select [dAP], set value ►
dAP-value=responsetimebetweenpressurechangeand
change of the switching status in ms�
The value for [dAP] defines the switching frequency (f) of the output:
dAP 3 6 10 17 30 60 125 250 500
f[Hz] 170 80 50 30 16 8 4 2 1
8.3.5 Setting the output logic
Select[P-n]andset[PnP]or[nPn]. ►
8.4 Service functions
8.4.1 Reading the max. value for the system pressure
Select [HI], press [Set] briefly� ►
Delete memory:
Select [HI]� ►
Press[Set]until[----]isdisplayed. ►
Press [Mode/Enter] briefly� ►
