IFM Efector500 PY7102 - Operating and Display Elements

6
6 Operating and display elements



 
     


1 - 8: Indicating LEDs
-LED1-LED3=systempressureinunitofmeasurementasindicatedonthelabel.
-LEDs4-6:notused.
-LED7,LED8=switchingstateoftherespectiveoutput.
9: 4-digit display
-Displayofthesystempressure.
-Displayofparametersandparametervalues.
10: Set pushbutton
Setting of the parameter values (scrolling by holding pressed, incremental by pressing -
briefly)�
11: Mode/Enter pushbutton
Selectionoftheparametersandacknowledgementoftheparametervalues. -
