22
SETTING
1. Languages:
The “Language“ option allows the user to select the
desired language�
2. Display:
The ”Display“ option allows the user to change the
background color and brightness of the working screen�
3. Sound:
The ”Sound” option allows the user to activate/deacti-
vate the key tone�
4. Factory Settings:
Select the ”Factory settings” option by turning and
pressing the rotary/push knob� The system requests
confirmation to restore the factory settings� Pressing the
”OK” button resets all the system settings to the origi-
nal standard values set at dispatch from the factory (see
"Menu structure")�
5. Communication:
The ”Device name” menu option allows you to edit the de-
vice name� This can relatively identify the paired station�
The ”Bluetooth
®
” menu option allows you to activate/
deactivate the ”Bluetooth
®
” function� A check mark
shows that the option is activated�
6. Information:
The ”Information” option offers the user an overview
of the most important system settings of the device�
SAFETY
1. Time out:
1) Set:
In the menu "Set", the user can determine a time limit
in the event of a communication breakdown between
the station and the WiCo� The station continues to
work with the preset target values until the preset time
value has expired� Following that, the station runs using
the preset safety temperature and safety speed�
OUTGAS
In the option, the user is allowed to set the outgas speed
in range of 1000 rpm to 4600 rpm and outgas interval
from 10 seconds to 240 seconds�
This function can be used when filling external devices
such as laboratory reactors�
Default Status: Defines the default state (OFF) of the
"M2-Output — Alarm" as "Open" or "Closed"� It de-
pends on the alarm type (normally open or closed)�
2) Switch:
Activates the switch output�
ON: Switches output into the active state (inverted initial
state)�
Note: When the "Program" is started, the M1 segment
settings have higher priority�
Default Status: Defines the initial state (OFF) of the
switch output as "Open" or "Closed"� It depends on the
switch type (normally open or closed)�
Temperature:
Temperature-dependent control of the M2-switch�
By entering the boundaries of “Higher” and “Low”, the
temperature range is set in which the M2-switch can be
opened�
If you activate a rule “Int / ext> Set Temperature” is an
automatic control of the M2-switch dependence on the
target temperature�
By the “Hysteresis” value (set temperature hysteresis) the
control stability can be optimized�
Note: int / ext stands according to the selected control
mode (internal (int) or external (ext)) for the actual tem-
perature to be controlled�
3. M3-Input:
Ext. Standby:
External standby input to stop the device functions Tem-
per and Pump�
ON: Activates the ext� standby function� Device func-
tions are stopped in the event of an inverted initial state
(ON) at the input�
Default Status: Defines the default state (OFF) of the in-
put as "Open" (high level) or "Closed" (low level)�
Note: The initial time out is 30 seconds and the user
can define up to 60 minutes for this time limit�
2) Speed:
In the “Speed“ menu, the user can specify a appropri-
ate and safe speed for specified temperature�
Note: The factory setting of the safe speed is 1000 rpm
and is activated after the time limit is set (see "Set")�
3) Temperature:
In the “Temperature“ menu, the user can specify a
temperature that is appropriate and safe for the circu-
lating task�
Note: The initial safe temperature is 30 ºC and is acti-
vated after the time limit is set (see "Set")�
2. Password:
In the "Password" menu, the menu settings can be
locked by a 3-digit password�
3. Safe Temp. Confirmation:
This menu allow you to confirm the safe temperature of
the station at start-up� This menu can confirm (safety
temperature of the station) at start-up of the set “Safe
Temp”� A check mark (√) indicates that the function is
activated�
