SWIFT K11-EN, Rev.A 41
[Set values editable within mode]
It displays the list of splice mode saved on sealer data to
facilitate selection of a proper mode to use.
Among splice modes saved on database, it copies a similar
splice mode to use editing function.
Mode title 1 is to indicate splice mode within 11 letters at
maximum.
Eccentricity
adjustment
function
When arraying optical fiber by using eccentricity adjustment
function, it sets offset ratio of axis.
The closer it is arrayed to the core center with fewer errors ,
the quicker and better the discharge is done.
It conducts tensile force test after splice.
It sets cutting angle’s error bound.
When either of cutting angles on both optical fiber is outside
the bound, error message is displayed.
Limit on
estimated loss
value
It sets estimated loss value’s error bound.
When estimated loss is higher than the bound, error message
is displayed.
Limit on optical
fiber angle
When the bending of 2 spliced optical fibers exceeds the set
bound, error message is displayed.
Cleaning
discharge
amount
A short cleaning discharge is conducted to remove fine dust
on optical fiber’s surface upon initial stage of optical fiber
arrayal. It sets intensity of cleaning discharge.
It sets time for cleaning discharge.
Upon final arrayal, it sets clearance of cross section between
both optical fibers.
It sets location of optical fiber spliced at the center of
discharge.
When MFD of both optical fibers differs, do the sealing
procedure through melting the smaller MFD optical fiber
more than the bigger MFD optical fiber. To heat the smaller
MFD optical fiber more, splice loss can be lowered by moving
the clearance location toward the bigger MFD optical fiber at
the center of discharge.
It sets initial discharge amount from the beginning of
discharge before optical fiber’s advance. If the value of initial
discharge amount is too low, the angle of optical fiber’s cross
