discharge
amount
section is poor and consequently, offset can be incurred on
the axis and if it is too high, optical fiber can be burned too
much or made round and consequently, splice loss value can
be big.
Initial discharge
time
It sets initial time from the beginning of discharge before
optical fiber’s advance. If [initial discharge time] is long, it
means the same that [initial discharge amount] gets big.
Overlap
It sets duplication of optical fiber on optical fiber’s advance
amount.
If [initial discharge amount] is weak or [initial discharge time]
is short, set the [overlap] somewhat small and if discharge
amount is strong and the time is long, set it somewhat big.
Discharge
amount 1
Main discharge can be adjusted in 2 levels.
The first level of discharge is [discharge amount 1] and the
second is [discharge amount 2]. [Discharge amount] 1 is set
in this area.
Discharge time 1
It sets time for [discharge amount 1].
Discharge
amount 2
[Discharge amount 2] is the second level of discharge.
[Discharge amount 2] is set in this area.
Discharge time 2
It sets time for [discharge amount 2].
Editable
It sets time for [discharge amount 2]. [Discharge time 2] is
generally set as “OFF.”
It can set the discharge time as a very long time period but
when [discharge time 1] and [discharge time 2] exceed 30
seconds, electrode can be damaged.
Time period for
discharge 2 being
On
While [discharge amount 2] is on discharge, you can set the
discharge amount as ON and OFF in turn. Time period for
[discharge amount 2] being On is set in this area. For re-
discharge, set the discharge time as “ON” at all times.
Time period for
discharge 2 being
Off
It sets time period for discharge of [discharge amount 2] is
turned off.
When [discharge amount 2] is occasionally stopped, re-
discharge can also be stopped. When re-discharge is
continuously required, set as “OFF.”
Re-discharge
time
It sets re-discharge time.
Editable
Within [splice mode edition], it automatically sets to
discharge the re-discharge amount with the same intensity as
that of [discharge amount 2].
If [discharge amount 2] is set as ON/OFF, re-discharge is
automatically changed.
Pulling splice
When optical fiber is made thin, splice loss is sometimes
increased. This pulling function is set as “OFF.” The
following 3 parameters decide the pulling shape.
Unedietabl
e
