The final voltage will be reached at the end of
process.
The internal temperature of the charger and the
temperature of battery being charged.
(The external temperature only will be displayed
when using the thermal probe.)
The present voltage of input DC power.
Display
DEC
DEC
DEC
DEC
DEC
INC
Using the individual connection cable to the
battery, you can check the individual voltages of
each cell in the battery pack. When connect the
cable to the port on the right side of the charger
the program shows them for maximum 8 cells in
sequence. To utilize this feature, the battery pack
must have output connector that linked to each
cells.
25
