Immergas SUPER TRIO - Main Components Solar Heating System Coupling Kit (Optional)

35
INSTALLERUSER
MAINTENANCE TECHNICIAN
1
2
3
4
5
6
7
43
1.21 MAIN COMPONENTS SOLAR HEATING SYSTEM COUPLING KIT OPTIONAL.
Key:
1 - Expansion vessel / Expansion tank
2 - Solar control unit
3 - Plate heat exchanger
4 - Circulation unit
5 - Safety valve
6 - Can
7 - Interception cock
