8
INSTALLERUSER
MAINTENANCE TECHNICIAN
a
1
A
4
Installation drawings key:
Unmistakeable component identication
Sequential identication of the operation to perform
Identication of generic or not supplied component
1.6 INSTALLATION.
Pack composition.
Ref. Description Q.ty
a Storage tank / Cylinder 1
b Storage tank 1
c Single zone hydronic group 1
d Accessories and screws 1
d
a
b
c
