52
INSTALLERUSER
MAINTENANCE TECHNICIAN
3.5 TECHNICAL DATA.
Maximum central heating circuit pressure bar 3.0
Maximum domestic hot water circuit pressure bar 8.0
Max. central heating circuit temperature °C 90
Max. domestic hot water circuit operating temperature °C 95
DHW expansion vessel l 16.0
DHW expansion vessel pre-charged pressure bar 2.5
Water content in the storage tank l 237
Full hydronic unit weight kg 35
Empty hydronic unit weight kg 26.3
Full 30 L inertial storage tank weight kg 23
Empty 30 L inertial storage tank weight kg 54
Full storage tank unit weight kg 298
Empty storage tank unit weight kg 61
Dispersions kW/24h 2.112
Psbsol W/K 1.96
Electrical connection V/Hz 230 / 50
Nominal power absorption (with optional) A 0.36 (0.7)
Nominal installed electric power (with optional) W 70 (140)
Power absorbed by the direct zone pump W 47
Power absorbed by the mixed zone pump (optional) W (47)
System pumps EEI value ≤ 0.20 - Part. 3
Equipment electrical system protection - IPX5D
