3.26 COMBUSTION PARAMETERS.
Victrix Pro 80 2ErP
G20 G31
Gas nozzle diameter mm 12.70 8.50
Supply pressure mbar (mm H
2
O) 20 (204) 37 (377)
Flue ow rate at nominal heat output kg/h 114 120
Flue ow rate at min heat output kg/h 13 13
CO
2
at Q. Nom./Min. % 9.95 / 8.95 10.60 / 9.75
CO with 0% O
2
at Nom./Min. Q. Nom./Min. ppm 233 / 4 175 / 4
NO
X
at 0% of O
2
at Q. Nom./Min. mg/kWh 34 / 1 65 / 6
Flue temperature at nominal output °C 62 61
Flue temperature at minimum output °C 43 42
Victrix Pro 100 2ErP
Gas nozzle diameter mm 11.30 8.40
Supply pressure mbar (mm H
2
O) 20 (204) 37 (377)
Flue ow rate at nominal heat output kg/h 146 148
Flue ow rate at min heat output kg/h 16 16
CO
2
at Q. Nom./Min. % 9.40 / 9.00 10.60 / 10.10
CO with 0% O
2
at Nom./Min. Q. Nom./Min. ppm 210 / 5 230/ 1
NO
X
at 0% of O
2
at Q. Nom./Min. mg/kWh 62 / 8 67 / 10
Flue temperature at nominal output °C 53 54
Flue temperature at minimum output °C 45 45
Victrix Pro 120 2ErP
Gas nozzle diameter mm 16.50 9.70
Supply pressure mbar (mm H
2
O) 20 (204) 37 (377)
Flue ow rate at nominal heat output kg/h 174 183
Flue ow rate at min heat output kg/h 19 19
CO
2
at Q. Nom./Min. % 9.80 / 9.00 10.60 / 10.00
CO with 0% O
2
at Nom./Min. Q. Nom./Min. ppm 257 / 1 220 / 1
NO
X
at 0% of O
2
at Q. Nom./Min. mg/kWh 95 / 9 77 / 13
Flue temperature at nominal output °C 56 56
Flue temperature at minimum output °C 46 46
