e cover kit includes:
N° 1 ermoformed cover
N°1 Gasket clamping plate
N°1 Gasket
N°1 Gasket tightening clip
N°1 Intake hole covering plate
N°1 Diaphragm (for Victrix Tera 28 only)
e terminal kit includes:
N° 1 Gasket
N° 1 Exhaust ange Ø 80
N° 1 Ø 80 90° bend
N° 1 Exhaust pipe Ø 80
N° 1 Wall sealing plate
