2.6 INFORMATION MENU.
By pressing the button “ “, the “Information menu” is activated
for at least 1 second, displaying some boiler operating parameters.
To scroll through the various parameters, press the buttons “DHW
regulation” “ “.
With the menu active on the indicator (19) the parameter via the
letter “d” plus the number of the parameter that is being displayed
will alternately show.
To view the parameter value, select it by pressing the button
.
Press “ ” or wait 15 minutes to go back to the previous
screen or exit the menu.
Parameter ID Description
d 0.0 Not used
d 0.1 Displays the ame signal (uA)
d 0.2 Displays the primary heat exchanger output instant heating ow temperature
d 0.3 Displays the instant output temperature from the DHW exchanger
d 0.4 Displays the values set for central heating set
d 0.5 Displays the values set for DHW set
d 0.6
Displays the external environment temperature (if optional external probe present)
If the temperature is below zero, the value is displayed ashing.
d 0.7 Displays the temperature of the inlet DHW (with optional DHW inlet probe present)
d 0.8 Displays the system return water temperature
d 0.9
Displays the list of the last eight anomalies.
(to scroll the list press the “central heating temperature regulation” buttons (6 and 7))
d 1.0
Anomaly list reset. Once “d 1.0” is displayed, press the Reset button for at least 3 seconds; deletion is conrmed via the “88”
symbols ashing for two seconds
d 1.1 Not used
d 1.2 Displays the pump operating speed
d 1.3 Not used
d 1.4 Displays the pump ow rate (lh/100)
d 1.5 Displays the fan operating speed (rpm/100)
d 1.6 Displays the temperature read on the ue probe
d 1.7 Displays the calculated ow temperature
d 1.8 At the end of the screed heater function, displays for how many hours the ow temperature remained at “Top set”
d 1.9 Toggles between the safety soware version and the functional soware version
d 2.0 Displays the ow temperature of zone two (optional)
d 2.1 Displays the ow temperature of zone three (optional)
d 2.2 Not used
