1.14 OUTDOOR INSTALLATION IN PARTIALLY
PROTECTED AREA.
A partially protected area is one in which the appliance
is not exposed to the direct action of the weather (rain,
snow, hail, etc.).
is type of installation is only possible
when permitted by the laws in force in
the appliance's country of destination.
If the appliance is installed in a place where the
ambient temperature drops below -5 °C, use the op-
tional antifreeze kit, checking the ambient operating
temperature range shown in the technical data table
in this instruction booklet.
Configuration type B, open chamber and fan assisted
(B
23
or B
53
).
Using the special cover kit one can achieve direct air intake (Fig.
13) and ue exhaust in a single chimney or directly outside. In this
conguration it is possible to install the boiler in a partially pro-
tected place. In this conguration the boiler is classied as type B.
With this conguration:
- air intake takes place directly from the environment in which
the appliance is installed (external);
- the ue exhaust must be connected to its own single chimney
(B
23
) or ducted directly outside via a vertical terminal for direct
exhaust (B
53
) or via an Immergas ducting system (B
53
).
e technical regulations in force must be respected.
Cover kit assembly (Fig. 14).
Remove the two plugs from the lateral intake holes. Now cover
the le intake hole using the relevant plate, xing it onto the right
side using the 2 previously-removed screws. Install the Ø 80 outlet
ange on the central hole of the boiler, taking care to insert the
gasket supplied with the kit and tighten by means of the screws
provided. Install the upper cover, xing it using the 4 screws
present in the kit, positioning the relevant gaskets.
ATTENTION:
the diaphragm in the Victrix Tera 28
model in the kit, must necessarily be
inserted in the Ø 80 ange, ensuring it stops.
Engage the 90° Ø 80 bend with the male end (smooth) in the
female end (with lip seal) of the Ø 80 ange unit to the end stop.
Introduce the gasket, making it run along the bend. Fix it using
the metal sheet plate and tighten by means of the clips present in
the kit, making sure to block the 4 gasket aps. Fit the male end
(smooth) of the exhaust pipe into the female end of the 90° Ø 80
bend, making sure that the relevant wall sealing plate is already
tted; this will ensure hold and joining of the elements making
up the kit.
Max. length of exhaust pipe.
e exhaust pipe (both vertical or horizontal) can be extended to
a max. length of 30 linear metres.
Coupling of extension pipes.
To install push-tting extensions with other elements of the
ue, proceed as follows: Fit the pipe or elbow with the male side
(smooth) in the female side (with lip seal) to the end stop on the
previously installed element. is will ensure sealing eciency
of the coupling.
Conguration without cover kit in a partially protected location
(type C boiler).
By leaving the side plugs tted it is possible to install the appliance
externally without the cover kit. Installation takes place using the
Ø60/100 and Ø 80/125 concentric intake/ exhaust kits. Refer to
the paragraph on indoor installation. In this conguration the
top cover kit guarantees additional protection for the boiler. It is
recommended but not compulsory. e Ø 80/80 separating device
cannot be used in this conguration (coupled with the cover kit).
