8. Function of the connector plugs
External solenoid valve
Over this plug the solenoid valve is supplied with mains voltage when it’s needful, before deioniser
cartridge. Maximum capacity up to 1A. Without this valve, the machine won’t work because of reasons for safety.
External leach pump
Here, you can connect, if necessary, an additional pump, for exalt the discharge head of waste water.
At the plug is mains voltage while draining. Current: max. 1A.
External error message
On this connection mains voltage is present while a breakdown of the machine.
Current: max. 1A. The error message is shown on the display.
External conductivity measurement
Here, your can connect the conductivity measurement of the deioniser cartridge if available.
