IMO VXSM75-1 - Alternative Motor Parameters (A Group)

Selecting Functions 5-9
5
Min. Factory
Name Setting range unit setting
A01 Maximum frequency 2 50 to 400Hz 1Hz 50 X 0
A02 Base frequency 2 25 to 400Hz 1Hz 50 X 0
A03 Rated voltage 2 0V, 80 to 240V(200V class) 1V 230 X 0
(at base frequency 2) 0V,160 to 480V(400V class) 400
A04 Maximum voltage 2 80 to 240V (200V class) 1V 230 X 0
(at maximum 160 to 480V(400V class) 400
frequency 2)
A05 Torque boost 2 0,1,2,3 to 31 1 0 0
A06 Electronic thermal 0: Inactive 1 1 0
overload relay 1: Active (for general purpose motors)
for motor 2 (Select) 2: Active (for inverter motors)
A07 (level) 20 to 135% of the rated inverter current 0.01A
rated 6
motor current
A08 (Thermal time 0.5 to 10 min. 0.1min 5.0 2
constant)
A09 Torque vector control 0:Inactive 1 0 X 0
2 1:Active
A10 Number of motor 2 to 14 2 4 X 0
2 poles
A11 Motor 2 (Capacity) 0.01 to 5.5kW (4.0kW or smaller)
0.01kW Nominal kW X 4
0.01 to 11.00kW(5.5/7.5kW)
applied
motor kW
A12 (Rated current) 0.00 to 99.9A 0.01A
standard X6
rating
A13 (Tuning) 0: Inactive
1: Active (%R1, %X)
2: Active (%R1, %X, Io) 1 0 X 12
A14 (Online tuning) 0: Inactive, 1: Active 1 0 X 0
A15 (No-load current) 0.00 to 99.9A 0.01A
standard X6
rating
A16
_
R1 setting
_
0.00 to 50.00% 0.01% standard 4
rating
A17
_
X setting
_
0.00 to 50.00% 0.01% standard 4
rating
A18 (Slip compensation 0.00 to 15.00Hz 0.01Hz 0.00 4
control 2)
A19 (Slip compensation 0.01 to 10.00s 0.01s 0.50 4
response time 2)
Function code
Change during operation
RS485 Data format
User setting
Description of change during operation
: The data changed by the or key takes
effect on the inverter operation. However,
press the key to store the new data.
V
V
: Press the or key to change the data.
The new data takes effect after the key is
pressed to store the data.
X : The data can be changed only while the
inverter is stopped.
V
V
FUNC
DATA
FUNC
DATA
A: Alternative motor parameters
