Installation of InfiNet Wireless R5000
Installation of InfiNet Wireless R5000
14
1.
2.
3.
4.
5.
3.1.2 Cable gland assembly for R5000-Smn/Lmn/Smnc
models
Required components:
FTP Cat5e cable
Shielded RJ-45 connector
Unshielded RJ-45 connector
Cable sealing nut
Cable gland case
Step 1
Put the cable sealing nut (4) and the cable gland case (5) onto the cable as shown on
the picture
Crimp the unshielded RJ-45 connector (3) onto the cable using the crimping tool
