Installation of InfiNet Wireless R5000
Installation of InfiNet Wireless R5000
16
1.
2.
3.
Tighten the sealing nut (4). Do not apply excessive force.
3.1.3 Console cable connector soldering scheme
Figure - Console cable connector soldering scheme
3.2 InfiNet Wireless R5000-Omx/Omxb Installation
Guidelines
Unpack the equipment
Check items integrity
Prepare RF cables of the required length. For 5GHz devices the recommended maximal
RF cable length is 1 meter
NOTE
A properly assembled cable gland seales against humidity.
