Installation of InfiNet Wireless R5000

3.7.2 Possible variants of Installation

Bellow are two schemes with installation on a pole of big diameter and on a wall

Figure - Installation scheme

3.8 InfiNet Wireless R5000-Smn(c) 5-6 GHz, 19 dBi

Installation

R5000-Smn(c) 5-6 GHz, 19 dBi supports several installation options such as pole mounting

using the supplied clamps and pipe/wall/pole mounting using the optional mount kit MONT-KIT-

.85c

NOTE

MONT-KIT-85 does NOT contain worm drive hose clamps or other additional

fixtures used in possible variants of installation.
