AUX-ODU-LPU-G Cable Ggland Assembly
In order to ensure that the cable gland remains sealed under any environmental conditions,
please, follow the assembly sequence according to the procedure below:
1) Put the cable gland nut (1), the split sealing grommet (2) and the cable gland threaded
coupling (3) onto the cable FTP Cat5e.
2) Crimp the connector onto the cable using the crimping tool.
For connection to "ETH IN" terminate the cable with the standard RJ-45 connector (4)
according to the EIA/TIA-568B.
For connection to "ETH OUT" terminate the cable with the shielded RJ45 connector (5)
according to the EIA/TIA-568B (to provide grounding circuit).
3) Insert the connector of the pre-terminated cable into the corresponding socket until you hear
a click.
4) Screw the cable gland threaded coupling (3) into the port and tighten it. Do not apply
excessive force.
5) Tighten the sealing grommet (2) by the cable gland nut (1). Do not apply excessive force.
CAUTION
Make sure that the RJ-45 connector is well-crimped. A loose connector can damage
the device. Please note that such damage is not covered by the warranty.
NOTE
Allowed to use a pre-crimped cable with RJ-45 connectors.
