Installation of InfiNet Wireless R5000
Installation of InfiNet Wireless R5000
30
Item Name
1 Cable gland nut
2 Sealing grommet
3 Cable gland threaded coupling
4 Unshielded RJ-45 connector
5 Shielded RJ-45 connector
Figure - AUX-ODU-LPU-G Cable Gland Assembly Scheme
