29
Copyright © 2004-2012 by InfiNet Wireless
ODU LED indicators description
InfiNet Wireless ODU units have two LED indicators (red and green) located in
the Console connector. These LEDs are useful in monitoring the device status
during the installation procedure. LEDs modes and Device status correspondence
is shown in the following table:
Red
indicator
Green
indicator
Device status
Off Off Device is switched off of in the process of start-up booting
Off Blinking
Device is booted. No radio connection. Searching for another
device to establish radio connection to.
Blinking On
Radio connection established. The more data is transmitted
through the radio channel the more frequently red indicator is
blinking.
R5000-Smnc model has a special LED indicator set located at the back of each
device designed to provide basic status information.
LED Status Device status
PWR On The device is powered on
RF Blinking RF-link is being established
On RF-link established
ETH On Wired link established
Signal level
This scale displays current RF signal level and is designed to
provide assistance in device alignment and link quality estimation
