73
Copyright © 2004-2012 by InfiNet Wireless
The “System Log” section allows browsing the unit’s system log. It is possible to
minimize/enlarge the system log window with the following buttons:
.
The “Clear System Log” button deletes all the information from the system log.
To hide the “System Log” section press “Hide System Log” button.
Once the unit is wirelessly connected to the remote neighbor it is possible to
make extended diagnostic and optimization of this link. To do this just mouse-
click on the row containing the data of the wireless link you want to test (see the
picture below):
Then choose Antenna alignment tool, Performance tests or Graphs from the
appeared Extended Link Diagnostics window.
Antenna alignment tool
Graphical antenna alignment tool visualize antenna alignment process making it
quicker, easier and comfortable for the user.
