System, Environmental, and Power Specifications
For the Infoblox 1400 Series Platforms 17
System, Environmental, and Power Specifications
System specifications describe the physical characteristics of the Infoblox SoT 1405 Series appliances.
Environmental specifications describe Infoblox SoT 1405 Series temperature and moisture limits. Power
specifications describe the electrical range within which the appliance circuitry can operate.
Caution: Infoblox recommends provisioning power according to the AC or DC rated input current and maximum peak
power values listed in the specifications below.
System Specifications
• Form Factor: 1-U rack-mountable appliance
• Dimensions: 1.73” H x 17.36” W x 17.2” D (4.4 cm H x 44.1 cm W x 43.7 cm D)
• Weight: Approximately 24 to 28 pounds (10.9 to 12.7 kg)
• Ethernet Ports: MGMT, HA, LAN1, LAN2 – auto-sensing 10Base-T/100Base-T/1000Base-T
• Serial Port: DB-9 (9600/8n1, Xon/Xoff)
• USB Port: USB 3.0
• LCD Panel: LCD (liquid crystal display) with input buttons
• Safety: FCC, CE, TUV, CB, VCCI, C-Tick, KCC, CCC, NOM
Environmental Specifications
• Operating Temperature: 41 to 95 degrees F (5 to 35 degrees C)
• Storage Temperature: - 40 to 122 degrees F (-40 to 50 degrees C)
• Operating Relative Humidity: 10% to 90% (non-condensing)
Drive Activity LED LEDs that flash green to indicate the hard drive is processing data.
Fans A fan system (5 fans total) to help maintain optimum operating temperature. Do not obstruct.
UID LED Blue = UID is activated through pressing the UID button on the appliance
Blinking Blue = UID is activated through the Grid Manager or CLI command
Dark = UID is deactivated
When UID is activated, the LCD on the front panel blinks at the same time.
Power Supply Each power supply has a power outlet for connecting the appliance to a standard AC or DC (Direct
Current) power source.
Grounding Post For DC installations, you securely connect a grounding wire to the chassis and to earth ground,
which typically is the equipment rack on which you install the appliance. The mounting nut is
placed on the grounding post for convenience. Remove the mounting nut, place the grounding
wire connector onto the grounding post and replace the mounting nut. Ensure that it is snug.
Power LED The power indicator is green if the power supply has power and is dark if it does not have power.
Air Vent An air vent that allows warm air to flow out of the appliance. Do not obstruct.
Component Description
