System, Environmental, and Power Specifications
For the Infoblox 1400 Series Platforms 18
• Airflow CFM (Cubic Feet/Minute): 31 CFM
• Environmental Certification: WEEE and RoHS
Power Specifications
• AC Power Supply: 110 to 240VAC 600W (Maximum)
— Rated Input Frequency: 50 Hz to 60 Hz
— Rated Input Current: 8.0A at 115V AC, 4.0A at 230VAC
— Inrush Current: 35 A max at 264VAC
— Maximum Heat Output (BTU/hour): 636 Maximum
— Maximum Peak Power: 450 W at 100V to 240V AC input
— Power Factor: 0.98 at 115VAC / 60Hz, 0.94 at 230VAC / 50Hz
• DC Power Supply: -48v 450W GRND TERM, RING, VIN 12-10 AWG #10
— Rated Input Voltage: -48VDC
— Rated Input Current: 20A max at -36VDC, 10A max at -72VDC
— Maximum Inrush Current: 100A 2u sec max
— Maximum Heat Output (BTU/hour): 636 Maximum
— Maximum Peak Power: 450W at -48V DC input
DC Power Cable Color Codes
DC power cables ship with a label describing each lead. Each label is located near the pigtail leads. Table 4 lists
-48V DC power specifications. Note that no color coding standards exist for DC power connections. The color coding
used by the external DC power source at your site determines the color coding for the leads on the power cables
that attach to the terminal studs on each DC power supply.
Table 4 -48V DC Power Connector
Cable Pin Cable Color Description
1 Black Positive Return
2Red Negative Input Voltage
3 Green/Yellow Safety Ground
