26
Playing sound through the projector
This projector is equipped with a 20-watt stereo speaker system, a dedicated
microphone input, and advanced audio processing for superb audio performance.
External amplified speakers may also be connected using the audio-o
ut connector
on the projector.
This system has assignable audio. Aud
io 1, Audio 2 and/or the microphone can be
assigned in any combination through the Audio Inputs feature described on
page 33. NOTE: The microphone audio can be u
sed alone (with other audio
muted), or in conjunction with other audio simultaneously. The mixing of the
microphone audio and other audio inputs is handled through the Mic Volume menu.
By default, Audio 1 plus microphone is associated w
ith VGA 1 and VGA 2. Audio
2 plus microphone is associated with the Composite Video.
About the microphone input
• If you wish to use a microphone, connect a 3.5 mini jack cable Dynamic
Microphone to the projector.
• You can use a wireless microphone as long as a wireless mo
dule is attached to
the projector’s microphone input jack and it works well with the associated
devices. To ensure a quality use of the wireless microphone, it is recommended
that your microphone conforms to the specifications listed in the table below.
Signal Parameter Min Max
Microphone Transducer Principle Dynamic
Impedance 300 1K ohm
Frequency response 600 16k Hz
• There are two ways to adjust
the microphone volume.
• Adjust the microphone volume level in the Setup > Mic Volume menu.
• Press the Volume key on the keypad or remote to adjust the volume of the
projector speaker and audio-out signal.
• The microphone will work regardless of whether the projector is turned on or
soft-powered off, if the Always-On function “Microphone” is set to On.
• If the microphone is not working, check
the volume setting and cable
connection.
You might get feedback noise from the microphone when you are too close to the
speaker of the projector. Move the microphone away from the speaker of the
projector. The greater volume you require, the greater distance you need to be away
from the speaker to prevent feedback noise.
NOTE: Only Dynamic Microphones should be used. Do not use active (phantom-
powered) microp
hones as projector damage may occur.

InFocus IN3916 Specifications

General

Projection distance	0.75 - 1.65 m
Vertical scan range	23.5 - 85 Hz
Horizontal scan range	31.4 - 91.1 kHz
Projection technology	DLP
Contrast ratio (typical)	3200:1
Screen size compatibility	1.44 - 3.17 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	± 30 °
Resolution	1920 x 1200 pixels
Aspect ratio	16:10
RS-232 ports	1
Weight (imperial)	9.9 lbs
Dimensions (WxDxH)	320 x 251.5 x 127 mm
Power requirements	90-264V, 50/60Hz
Connectivity technology	Wired
Focal length range	- mm
Lamp power	220 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	4000 h
HD-Ready	Yes
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	10 W
Number of built-in speakers	2
DVI port	No
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
VGA (D-Sub) ports quantity	3
Noise level	35 dB
Certification	UL, c-UL, FCC, CE, C-Tick Mark, NOM, COFETEL
Power source	AC
Power consumption (standby)	- W
Power consumption (typical)	238 W
Operating temperature (T-T)	5 - 40 °C
Product type	Standard throw projector

Weight and Dimensions

Weight	4490 g
Package weight	6580 g
