InFocus IN3916 User Manual

39
LiteShow
The LiteShow Utility embedded in your projector provides many new features to
make your presentations even more effective. Once installed, the Utility allows you
to configure, control and display to your projector from a computer or PDA over
either a wired or wireless LAN connection. It also allows you to display up to 4
computer screens simultaneously, and includes a moderator control, allowing you
to control the display of up to 32 computers.
• Supports Windows 7, Vista, XP, 2000 and Mobile 5/6
•
S
upports Macintosh (Mac) version 10.4 and later
• Provides security login, wireless WEP/WPA key and Gatekeeper function to
protect information from theft
LAN Connection
LiteShow supports wired and wireless LAN connectivity for projector control and
display. There are three set-up options available.
• Wired only: projector can be accessed o
ver the connected LAN
• Wireless only: proje
ctor creates a wireless LAN which can be accessed by
802.11b/g enabled computers.
• Both wired and wireless: projector creates
a wireless LAN which can be
accessed by 802.11b/g enabled computers and which also can provide an
Access Point through the wired connection to the larger corporate network.
Projector can be accessed through either ether wireless or wired network.
Setting up a LAN connection:
Select the LAN source on the projector which will d
isplay the LiteShow splash
screen. Establish a network connection from your computer to the projector based
on the wired and/or wireless set-up implemented when the projector was installed.
Open a web-browser window and type the projector’s IP address to connect to the
projector’s LiteShow Login screen.
LiteShow Login Screen
At the LiteShow Login screen, enter one of the following combinations to access
associated LiteShow menus:
Login Default Password Menu Options
None Leave blank Download
System Status
Basic User trainer Download
System Status
Basic Projector Control
Moderator Control
Admin User admin Download
System Status
Basic Projector Control
Moderator Control
Admin Menu
If the default password listed above d
o
es not work, contact your IT administrator.

InFocus IN3916 Specifications

General

Projection distance	0.75 - 1.65 m
Vertical scan range	23.5 - 85 Hz
Horizontal scan range	31.4 - 91.1 kHz
Projection technology	DLP
Contrast ratio (typical)	3200:1
Screen size compatibility	1.44 - 3.17 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	± 30 °
Resolution	1920 x 1200 pixels
Aspect ratio	16:10
RS-232 ports	1
Weight (imperial)	9.9 lbs
Dimensions (WxDxH)	320 x 251.5 x 127 mm
Power requirements	90-264V, 50/60Hz
Connectivity technology	Wired
Focal length range	- mm
Lamp power	220 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	4000 h
HD-Ready	Yes
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	10 W
Number of built-in speakers	2
DVI port	No
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
VGA (D-Sub) ports quantity	3
Noise level	35 dB
Certification	UL, c-UL, FCC, CE, C-Tick Mark, NOM, COFETEL
Power source	AC
Power consumption (standby)	- W
Power consumption (typical)	238 W
Operating temperature (T-T)	5 - 40 °C
Product type	Standard throw projector

Weight and Dimensions

Weight	4490 g
Package weight	6580 g
