InFocus X17 User Manual

Operation36
Menu operation
Menu system
Please note that the on-screen display (OSD) menus vary according to the signal
type selected.
The menu items are available when the projector detects at least one valid signal. If
there is no equipment connected to the projector or no signal detected, limited
menu items are accessible.
Main menu Sub-menu Options
1.
DISPLAY
Wall Color
Off/Light Yellow/Pink/Light
Green/Blue/Blackboard
Aspect Ratio Auto/Real/4:3/16:9
Keystone
Position
Phase
H. Size
Digital Zoom
2.
Preset Mode
PC source: Brightest/Presentation/Photo/Cinema/
User 1/User 2
Video source: Brightest/Standard/Cinema/User 1/
User 2
Reference Mode
PC source: Brightest/Presentation/Photo/Cinema
Video source: Brightest/Standard/Cinema
Brightness
Contrast
Color
Tint
Sharpness
Brilliant Color On/Off
Color Temperature T1/T2/T3/T4
3D Color
Management
Primary Color R/G/B/Y/C/M
Hue
Saturation
Gain
Save Settings
3. SOURCE
Quick Auto Search On/Off
4.
SYSTEM
SETUP:
Basic
Presentation
Timer
Timer Period 1~240 minutes
Timer Display Always/1 min/2 min/3 min/Never
Timer Position
Bottom-right/Top-right/Bottom-
left/Top-left
Timer Counting
Direction
Count Down/Count Up
Sound Reminder On/Off
On/Off

InFocus X17 Specifications

General

Matrix size	0.55 \
Projection distance	1.49/6 m
Vertical scan range	56 - 85 Hz
Horizontal scan range	31.35 - 68.7 kHz
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	0.69 - 6.4 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-30/30 °
Aspect ratio	4:3, 5:4, 16:9
RS-232 ports	1
Dimensions (WxDxH)	223.5 x 263.9 x 111.8 mm
Power requirements	100 - 240 V, 50 - 60 Hz
Throw ratio	1.9 - 2.1:1
Lamp power	140 W
Light source type	Lamp
Service life of light source (economic mode)	4000 h
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	5 W
Serial interface type	RS-232
Noise level	29 dB
Power consumption (typical)	285 W
Operating temperature (T-T)	5 - 35 °C
Placement	Ceiling

Weight and Dimensions

Weight	2400 g
