InFocus X17 User Manual

Maintenance44
Lamp information
Getting to know the lamp hour
When the projector is in operation, the duration (in hours) of lamp usage is
automatically calculated by the built-in timer. The method of calculating the
equivalent lamp hour is as follows:
Total (equivalent) lamp hour
= 1 (hours used in Economic mode) + 4/3 (hours used in Normal mode)
See "Setting Lamp mode as Economic" below for more information on Economic mode.
The lamp hour in Economic mode is calculated as 3/4 of that in Normal mode.
That is, using the projector in Economic mode helps to extend the lamp hour by 1/
3.
To obtain the lamp hour information:
1. Press MENU/EXIT and then press / until the SYSTEM SETUP:
Advanced menu is highlighted.
2. Press to highlight Lamp Settings and press MODE/ENTER. The Lamp
Settings page displays.
3. You will see the Equivalent lamp hour information displaying on the menu.
4. To leave the menu, press MENU/EXIT.
You can also get the lamp hour information on the INFORMATION menu.
Extending lamp life
The projection lamp is a consumable item that normally can last up to 3000-4000
hours with proper usage. To keep the lamp life as long as possible, you can do the
following settings via the OSD menu.
Setting Lamp mode as Economic
Using Economic mode reduces system noise and power consumption by 20%. If
the Economic mode is selected, the light output will be reduced and result in
darker projected pictures.
Setting the projector in Economic mode also extends the lamp operation life. To
set Economic mode, go into the SYSTEM SETUP: Advanced > Lamp Settings >
Lamp mode menu and press / .
Setting Auto Power Off
This function allows the projector to turn off automatically if no input source is
detected after a set period of time to prevent unnecessary waste of lamp life.
To set Auto Power Off, go into the SYSTEM SETUP: Basic > Auto Power Off
menu and press / . The time period can be set from 5 to 30 minutes in 5-minute
increments. If the preset time lengths are not suitable for your presentation, select
Disable. The projector will not automatically shut down in a certain time period.

InFocus X17 Specifications

General

Matrix size	0.55 \
Projection distance	1.49/6 m
Vertical scan range	56 - 85 Hz
Horizontal scan range	31.35 - 68.7 kHz
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	0.69 - 6.4 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-30/30 °
Aspect ratio	4:3, 5:4, 16:9
RS-232 ports	1
Dimensions (WxDxH)	223.5 x 263.9 x 111.8 mm
Power requirements	100 - 240 V, 50 - 60 Hz
Throw ratio	1.9 - 2.1:1
Lamp power	140 W
Light source type	Lamp
Service life of light source (economic mode)	4000 h
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	5 W
Serial interface type	RS-232
Noise level	29 dB
Power consumption (typical)	285 W
Operating temperature (T-T)	5 - 35 °C
Placement	Ceiling

Weight and Dimensions

Weight	2400 g
