INFOSEC UPS SYSTEM E4 Evolution II TT Series User Manual

138
INFOSEC UPS SYSTEM – 15, Rue du Moulin – 44880 Sautron – France – www.infosec-ups.com
Hot Line Tel : +33 (0)2 40 76 15 82 – fax : +33(0)2 40 94 29 51 – hotline@infosec.fr – 02 19 AA 59 203 07
9. Technical specifications
MODEL
E4 Evolution II
100K TT S
E4 Evolution II
120K TT S
E4 Evolution II
160K TT S
E4 Evolution II
200K TT S
CAPACITY
100KVA / 90KW
120KVA / 108KW
160KVA / 144KW
200KVA / 180KW
INPUT
Voltage Range
208-478 VAC (3-phase) @ 70% of load
305-478 VAC (3-phase) @ 100% of load
Nominal Frequency
50Hz/60Hz(Auto-selectable)
Frequency Range
40Hz ~ 70Hz
Phase
3 Phase with Neutral(Three Phase, Neutral + Ground)
Synchronized Range
+/- 1Hz, +/- 2Hz, +/- 4Hz (default: 4Hz) User Programmable
Power Factor
≧ 0.99 at 100% Load
THDi (100% load)
< 3%@Full Load(@Linear Load)
* De-rating
Mains Input (Bypass)
Voltage
Range
Nominal Voltage
380V/400V/415V
Voltage Range
Upper limit: +10, +15 or +20, default: +15%
Lower limit: -10, -20, -30 default:-20%
Nominal Frequency
50Hz/60Hz(Auto-selectable)
Frequency Range
+/- 1Hz, +/- 2Hz, +/- 4Hz (default: 4Hz)
Phase
3 Phase with Neutral(Three Phase, Neutral + Ground)
Synchronized Range
+/- 1Hz, +/- 2Hz, +/- 4Hz (default: 4Hz) User Programmable
OUTPUT
Phase
3 Phase with Neutral(Three Phase, Neutral + Ground)
Output voltage
380/400/415VAC (Ph-Ph)
