220/230/240VAC (Ph-N)
AC Voltage Regulation
< 1% Typical (balanced load) < 2% Typical (unbalanced load)
Frequency Ra (Synchronize range)
40Hz ~ 70Hz
Frequency Range (Batt. Mode)
50 Hz ± 0.1 Hz or 60Hz ± 0.1 Hz
Overload
AC mode
1 hour for 105 ~110%, 10 mins for 111~125%, 1 min for 126~150%, 200ms for
>150%
Battery mode
1 hour for 105 ~110%, 10 mins for 111~125%, 1 min for 126~150%, 200ms for
>150%
Current Crest Ratio
3:1 max
Harmonic Distortion
100% linear load: <2% 100% nonlinear load: <4%
Transfer
Time
Line Battery
0 ms
Inverter Bypass
Synchronous transfer: <= 0ms Asynchronous transfer: < 1 cycle
Inverter ECO
<20 ms
EFFICIENCY
AC mode
94%, Line mode @ 100% R Load
93.5%, Line mode @ 50% R Load
ECO Mode
98%, ECO Mode @ 100% R Load
97%, ECO Mode @ 50% R Load
Battery Mode
93 %, Battery mode @ 100% R Load
92.5%, Battery mode @ 50% R Load
BATTERY
Type
Depending on applications
Numbers
32 36 40 (adjustable)
Maximum charging current*
24A**
32A**
40A**
48A**
Floating Voltage
2.29V/cell
Boost Charging
2.35V/cell
Charger Voltage Regulation
< 1%
Ripple Voltage
< 1%
Ripple Current (% C10)
< 5
PHYSICAL
Dimension D X W X H mm
945 x 567 x 1015
995 x 567 x 1455
Dual Input
Model
Net Weight(kg)
197
232
309
343
ENVIRONMENT

INFOSEC UPS SYSTEM E4 Evolution II TT Series Specifications

General

Brand	INFOSEC UPS SYSTEM
Model	E4 Evolution II TT Series
Category	UPS
Language	English
