INFOSEC UPS SYSTEM - 4, rue de la Rigotière – 44700 Orvault – FRANCE - www.infosec.fr
Hot Line: tel : + 33 (0)2 40 76 15 82 - fax : + 33 (0)2 40 94 29 51 - hotline@infosec.fr - 09 05 04 205 12
５２
5 Connection and Operation: E
4
700/1000(S)/2000(S)/3000(S)
The system has to be installed and wired only by qualified electricians in accordance with
safety regulations!
6. When installing the electrical wiring, please note the nominal amperage of your incoming
feeder.
5.1 Control
Inspection: when you receive your equipment, check out the packaging carton and its contents to make
sure there is no damage. Please inform immediately the carrier if you should find signs of damage.
Please keep the packaging in a safe place for future use.
Note:
Please make sure the incoming feeder is isolated and secured to prevent it from being
switched back on again.
5.2 Wiring
5.2.1 UPS Input Connection
If the UPS is connected via the power cord, please use a proper outlet with protection against electric
power cuts and pay attention to the capacity of the outlet: over 10A for E
4
1000(S) & 2000 and over 16A for
E
4
2000(S) & 3000(S).
5.2.2 UPS Output Connection
The output of E
4
1000(S) and 2000(S) are IEC female type outlets (4 and 6). Plug the load power cord to
the output outlets to complete connection.
Model No. Output Outlets Terminal Block
700 4
Nil
1000/1000S 4
Nil
2000 6 Nil
2000S 4 Yes
3000/3000S 4 Yes
Besides output outlets, E
4
2000S and E
4
3000/3000S are equipped with a terminal block available for
output as well.
