INFOSEC E 4 - 20 Appendix 2: LED Display for E⁴ 5000;6000;10000; LED Display and Alarm Table

INFOSEC UPS SYSTEM - 4, rue de la Rigotière – 44700 Orvault – FRANCE - www.infosec.fr
Hot Line : tel : + 33 (0)2 40 76 15 82 - fax : + 33 (0)2 40 94 29 51 - hotline@infosec.fr - 07 05 04 205 04
７９
20 Appendix 2- LED Display for E
4
5000/6000/10000
LED display Alarm warning
N° Operating state
1# 2# 3# 4# 5# 6# 7# 8# 9# 10#
1
0~35%
Load capacity
● ● ●
none
2
36%~55%
Load capacity
● ● ● ●
none
3
56%~75%
Load capacity
● ● ● ● ●
none
4
76%~95%
Load capacity
● ● ● ● ● ●
none
5
Utility
Power
Mode
96%~105%
Load capacity
● ● ● ● ● ● ●
none
6
0~20%
Battery capacity
● ● ●
Beep once every sec
7
21%~40%
Battery capacity
● ● ● ●
Beep once every 4 sec
8
41%~60%
Battery capacity
● ● ● ● ●
Beep once every 4 sec
9
61%~80%
Battery capacity
● ● ● ● ● ●
Beep once every 4 sec
10
Battery
Mode
81%~100%
Battery capacity
● ● ● ● ● ● ●
Beep once every 4 sec
11 Bypass mode ↑ ↑ ↑ ↑ ● ● ● Beep once every 2 min.
12
overloaded in utility mode and UPS still
in INV mode
● ● ● ● ● ● ● ●
Beep twice every sec.
13
overloaded in utility mode and UPS in
bypass mode
● ● ● ●
Continuously beep
14 Utility power abnormal ↑ ↑ ↑ ↑ ● ★ ↑ ↑ ↑ ↑
15
Overloaded in battery mode,
Early-warning
● ● ↑ ↑ ↑ ↑ ● ●
Beep twice every sec.
16
Overloaded in battery mode,
Cut off the output
● ●
Continuously beep
17 Over temperature ● ● ↑ ↑ Continuously beep
18 Inv abnormal ● ● ↑ ↑ Continuously beep
19 Output short circuited ● ● ● ↑ ↑ Continuously beep
20 BUS voltage abnormal ● ● ↑ ↑ Continuously beep
21 Charger or battery failed ● ● ● ↑ ↑ ★ Continuously beep
22 Battery voltage abnormal ↑ ↑ ↑ ↑ ↑ ● ● ★ ↑
23 BAT SCR failed ● ● ● Continuously beep
24 Fan abnormal ● ● ● ● ● Continuously beep
25 Bypass STS failed ● ● ● ● ● Continuously beep
26 INV RLY failed ● ● ● ● ● Continuously beep
27 Communication abnormal ● ● ● ↑ ↑ Continuously beep
● : Solid ON ★ : Flash ↑ : LED display and alarm warning are dependent on other conditions.
