9 Introduction – E
4
5000(S)/6000(S)/10000(S)
9.1 General specifications
Model E
4
5000 E
4
5000S E
4
6000 E
4
6000S E
4
10000 E
4
10000S
Power rating 5KVA/3,5KW 6KVA/4.2KW 10KVA/7KW
Frequency (Hz) 50
Voltage (176-276)VAC
Input
Current 25A max 31A max 50A max
Voltage 240VDC
Battery
Current 20A max 24A max 40A max
Voltage 220VAC
Output
Current 23A 27A 45A
Dimension (WxDxH) mm 260x570x717
Weight (kg) 90 35 90 35 93 38
9.2 Electrical Performance
Input
Tension Frequency Power factor
Single-phase 46Hz-54Hz >0.98 (full load)
Output
Voltage
Regulation
Power
Factor
Frequency
tolerance
Distorsion Overload capacity
Current
crest ratio
±1% 0.7 lag
Synchronized
46-54Hz in Line
mode (AC mode)
±0.1% of normal
frequency in
BATTERY mode
THD<2%
Full load
(Linear Load)
105%-130% load transfers to
bypass mode
after 10 minutes
>130% load transfers to
BY-PASS mode after 1 second
and shutdown the output after
1 minute
3:1 maximum
9.3 Operating Environment
Temperature Humidity Altitude
Storage temperature
0°C-40°C <95% <1000m 0°C-40°
Note:
if the UPS is installed or used in a place where the altitude is above than 1000m, the output
power must be reduced in use, please refer to the following:
Altitude (M) 1000 1500 2000 2500 3000 3500 4000 4500 5000
Decrease in power
100% 95% 91% 86% 82% 78% 74% 70% 67%
