E-PROMS AND KIT NUMBERS
10-40 INTELLISYS P/N
Current main program E-prom 39179585
Auto Start and Stop Prom Kit 39666672
Remote Start and Stop Kit 39666680
Instructions APDD305-89
Combination Start and Stop Kit 39666698
Sequencer Interface Kit 39674387
Instructions APDD405-90
Instructions Installation APDD403-90
-39-
DEGREE
F. TEMP. RES.
DEGREE
F. TEMP. RES.
DEGREE
F. TEMP. RES.
184 1033
185 1014
186 996.4
187 978.8
188 961.5
189 944.6
190 928.1
191 911.9
192 896.0
193 880.5
194 865.2
195 850.3
196 835.6
197 821.3
198 807.2
199 793.4
200 779.9
201 766.7
202 753.7
203 741.0
204 728.5
205 716.3
206 704.3
207 692.5
208 681.0
209 669.7
210 658.6
211 647.7
212 636.9
213 626.5
214 616.2
215 606.1
216 596.3
217 586.6
218 577.1
219 567.8
220 558.6
221 549.7
222 540.9
223 532.2
224 523.8
225 515.4
226 507.3
227 499.3
228 491.4
229 483.7
230 476.1
231 468.7
232 461.4
233 454.2
234 447.2
235 440.3
236 433.5
237 426.9
238 420.3
239 413.9
156 1744
157 1710
158 1677
159 1645
160 1614
161 1583
162 1553
163 1523
164 1495
165 1466
166 1439
167 1412
168 1386
169 1360
170 1335
171 1310
172 1286
173 1262
174 1239
175 1216
176 1194
177 1172
178 1151
179 1130
180 1110
181 1090
182 1071
183 1051
SSR 10-40 HP
INTERFACE BOARD TROUBLESHOOTING CHART
U-Series Voltage Chart
Interface board
TERMINAL #'S VOLTAGE CONDITION
5,16 115 VAC ENERGIZED
0 VAC DE-ENERGIZED
6,17 115 VAC ENERGIZED
0 VAC DE-ENERGIZED
7,18 115 VAC ENERGIZED
0 VAC DE-ENERGIZED
8,19 115 VAC ENERGIZED/UNIT RUNNING
0 VAC DE-ENERGIZED/UNIT STOPPED
9,10 115 VAC POWER ON
0 VAC POWER OFF
9,15 115 VAC ITAS CLOSED
0 VAC ITAS OPEN
1,2 0 VDC REMOTE START PB CLOSED
5 VDC REMOTE START PB OPEN
3,4 0 VDC REMOTE STOP PB CLOSED
5 VDC REMOTE STOP PB OPEN
28,29 0 VDC EITHER STARTER AUX CONTACT CLOSED
5 VDC BOTH STARTER AUX CONTACTS OPEN
30,31 0 VDC STARTER OVERLOAD CONTACT CLOSED
5 VDC STARTER OVERLOAD CONTACT OPEN
24,26 5 VDC POWER ON
0 VDC POWER OFF
23,25 VARIABLE WITH PRESSURE
0-50mVDC POWER ON
0 VDC POWER OFF
20,21 10K OHM @ 25 DEG. C POWER OFF *
* TAKE MEASUREMENT WITH POWER OFF
ALARM CONTACT POSITIONS
SSR 10 THROUGH 40 HORSEPOWER
BEFORE E-PROM REVISION LEVEL 9.0
NO POWER POWER POWER WITH ALARM
N.O.14 • • •
COM. 13 • • •
N.C. 12 • • •
REVISION LEVEL 9.0 AND HIGHER
NO POWER POWER POWER WITH ALARM
N.O. 14 • • •
COM. 13 • • •
N. C. 12 • • •
