SSR 50-450 HP
ANALOG BARRIER BOARD VOLTAGE CHART
Analog Barrier Terminal Printed Circuit Board
BTS-1
TERMINAL #'S VOLTAGE CONDITION
3,4 +5VDC POWER ON # 3 RED 5 VDC SUPPLY
3,4 0VDC POWER OFF # 4 BLACK GND
1,2 VARIABLE WITH PRESSURE
0-50mVDC POWER ON LINEAR
0 VDC POWER OFF
5 GROUND
8,9 +5 VDC POWER ON # 8 RED 5VDC SUPPLY
8,9 0VDC POWER OFF # 9 BLACK GND
6,7 VARIABLE WITH PRESSURE
0-50mVDC POWER ON LINEAR
0 VDC POWER OFF
10 GROUND
23,22 +5VDC POWER ON # 22 BLK 5 VDC SUPPLY
23,22 0VDC POWER OFF # 23 SHLD GND
21,22 VARIABLE DUE TO TEMPERATURE #21 WHT SIGNAL
10K OHM WITH TEMPERATURE @ 25 DEG. C.
WITH POWER OFF *
25,26 +5VDC POWER ON # 25 BLK 5 VDC SUPPLY
25,26 0VDC POWER OFF # 26 SHLD GND
24,25 VARIABLE DUE TO TEMPERATURE #24 SHT SIGNAL
10K OHM WITH TEMPERATURE @ 25 DEG. C.
WITH POWER OFF *
* TAKE MEASUREMENT WITH POWER OFF
* TAKE MEASUREMENT WITH POWER OFF AND THERMISTOR
DISCONNECTED
BTS-2
TERMINAL #'S VOLTAGE CONDITION
3,4 +5VDC POWER ON # 3 RED 5 VDC SUPPLY
3,4 0VDC POWER OFF # 4 BLACK GND
1,2 VARIABLE WITH PRESSURE
0-50mVDC POWER ON LINEAR
0 VDC POWER OFF
5 GROUND
22,23 +5VDC POWER ON # 22 BLK 5 VDC SUPPLY
22,23 0VDC POWER OFF # 23 SHLD GND
21,22 VARIABLE DUE TO TEMPERATURE # 21 SHT SIGNAL
10K OHM WITH TEMPERATURE @ 25 DEG. C.
WITH POWER OFF. *
T3 ELECTRONIC CONTROL TRANSFORMER TERMINAL J1
TERMINAL #'S VOLTAGE CONDITION
1,6 115VA C POWER ON
1,6 0 VAC POWER OFF
2,4 7.1VA C POWER ON
2,4 0 VAC POWER OFF
3,5 7.1VA C POWER ON
3,5 0 VAC POWER OFF
BTS-3
TERMINAL #'S VOLTAGE CONDITION
1 GROUND
5,2 +5VDC POWER ON
5,2 0VDC POWER OFF
3,2 +5VDC INLET VALVE CLOSED AND COUPLING
ENGAGED IN LOWER LIMIT SWITCH
3,2 0VDC INLET VALVE NOT CLOSED
4,2 +5VDC INLET VALVE OPEN AND COUPLING ENGAGED
IN UPPER LIMIT SWITCH
4,2 0VDC INLET VALVE NOT OPEN
6,7 5-12 OHMS POWER OFF *
6,7 10-20 VDC POWER ON PHASE ON
0 VDC POWER ON PHASE OFF
8,9 5-12 OHMS POWER OFF *
8,9 10-20 VDC POWER ON PHASE ON
0 VDC POWER ON PHASE OFF
TERMINAL # VOLTAGE CONDITION
J2 COM PORT 0-5VDC
J3 LOW VOLTAGE DC (0,5,10VDC)
* DO NOT ATTEMPT RESISTANCE MEASUREMENT WITH POWER ON.
50-100 HP APPROXIMATELY 6 OHMS
125-300 HP APPROXIMATELY 8 OHMS
300-450 HP APPROXIMATELY 12 OHMS
