Programming the SmartLink-GP 27
Programming manual
Output - ON Time
For pulse outputs only — determines the
pulse length.
Output - Buzzer
To be used when the output is connected
to an external buzzer. In this case,
activation generates an audible signal
(beep) which persists for the entire ON
status (if the output is a pulse output —
for the set ON Time, if the output is a
bistable output — until standby status is
restored). During ON Time, a signal
between 0 and 5V @ 1KHz frequency will
be present on the terminal.
Output - LED
To be used when the output is connected
to an external LED. In this case, activation
generates a visual signal (LED ON) which
persists for the entire ON status (if the
output is a pulse output — for the set ON
Time, if the output is a bistable output —
until standby status is restored).
If you want the LED to
blink, click on the
respective check box.
Blinks @ 2Hz frequency
(0.25 seconds ON an
0.25 seconds OFF). Do
not click on the check
box, if you want the
LED to be solid.
Output - Confirm
If an output activates/deactivates as the
result of an incoming call or SMS text
command, SmartLink-GP can be set up to
send a feedback ring and/or SMS text to
the caller. Caller ID must be enabled.
For example, if the
name assigned to the
output is "Heating
system" (refer to
Descriptions), the
Output- Confirm SMS
will be"Heating system
OK".
Input - Type
Enabled when SmartLink-GP is used as an
Intrusion control panel.
See paragraph 3.8
Programming the
SmartLink-GP as an
Intrusion control panel.
Para-
meter
Description Note
