38 Programming the SmartLink-GP
Programming manual
3.10.4 Send an event-triggered Contact ID report
Figure 11 - Events table - Contact ID
Each event can trigger and send a Contact ID report to a specific phone
number.
For example, an input zone alarm event to the central station.
Parameter Description Note
Contact ID
dialler
Folder containing Contact ID
report parameters. Double
click to open: columns
containing the successive
parameters will appear.
Double click to close.
=no parameter
has been set
=some
parameters have been
set.
Protocol
class
ContactID protocol class The
event protocol class must be
approved by the central
station.
Event code 2 digit hexadecimal code The Code must be
approved by the central
station.
Qualifier New for a new event,
Restored for a cleared event.
In report coding New=1 and
Restore=3.
Phone
numbers
Check boxes corresponding to
the phone numbers for
outgoing calls set up in the
Phonebook. The phone
number description appears
when you mouse over the
respective number on the
tooltip bar.
See the Call all
Contact ID numbers
option to choose
whether the message
must reach only one of
the dialed phone
numbers or all of them
successfully.
