Programming the SmartLink-GP 53
Programming manual
•Activate output
• Clear call queue
If the Enable GSM answerphone option has been selected, SmartLink-GP
will answer incoming DTMF tones on the GSM network. If the Enable PSTN
answerphone option has been selected, SmartLink-GP will answer
incoming DTMF tones on the land line (PSTN). If neither of these options has
been selected, DTMF tones will be ignored. Both options can be enabled
contemporarily.
Note: For land line (PSTN) calls, check the setting of the Double
call option. See “paragraph 3.7 Programming the Inputs
and Outputs — IN&OUT”.
If you are making an status enquiry call to SmartLink-GP, or you are
receiving for example a 'flood alarm' voice call from SmartLink-GP, you will
automatically access DTMF mode which, in the case of the 'flood alarm' call,
will allow you to turn off the water supply at the mains.
3.14.1 Sending the DTMF tone sequence
If you are calling the SmartLink-GP via GSM network or
PSTN:
1. Make the call.
If SmartLink-GP is calling you:
1. Press ‘#’
Access the DTMF menu:
2. Wait for 4 feedback beeps (access confirmed)
3. #UserCode# (e.g. “#005122#”)
4. Wait for a feedback beep (access confirmed)
5. Press ‘#’ to access the DTMF menu
6. Type in a Control code (‘0’, ‘1’, ‘4’, ‘5’)
7. Work carefully through the specific instructions for each code, as
follows.
Note: If (from the parameters table) the DTMF menu without
code option is enabled, and you receive a call from the
device, you can omit the user code from the sequence, by
skipping stepa 3, 4, 5.
Note: Press ‘#’ at any point to go back to the main menu or ‘*’ to
end the call.
