Inner Range 3000 User Manual

MODEL 3000 / ACCESS 4000. CE Installation Notes.
2
Contents
ELECTRICAL & MECHANICAL SPECIFICATIONS ...........................................................................................2
CONTROL MODULE PARTS LIST ........................................................................................................................3
INSTALLATION INSTRUCTIONS .........................................................................................................................4-5
WIRING DIAGRAMS ...............................................................................................................................................6-7
THE CONTROL MODULE PCB
Link and Connector details.........................................................................................................................................8-9
Fault LED indications and LCD Terminal Error Messages .......................................................................................9
Control Module PCB layout .......................................................................................................................................10-11
LAN SYSTEM OVERVIEW .....................................................................................................................................12
Connecting Modules to the LAN ...............................................................................................................................12-13
System Earthing..........................................................................................................................................................12
Cable Types ................................................................................................................................................................14
System cabling configuration .....................................................................................................................................15
LAN Termination Details ...........................................................................................................................................15
Troubleshooting Flowchart ........................................................................................................................................16 & 17
LAN Voltage Testing .................................................................................................................................................18
SYSTEM OPTIONS. PIC Micro Options (U14) ......................................................................................................19
MENU FLOWCHART...............................................................................................................................................20
Electrical Specifications
Power Supply Input: Transformer Input Voltage: 240V AC -10% / +10%. 50 Hertz.
Transformer Output Voltage: 16.5V AC. 50 Hertz.
Current Consumption: Maximum 500 milliAmps from 240V AC Source.
Fuse Protection: Separate AC mains input fuse. 500 milliAmps. 8AG (25mm)
PCB AC Input Voltage: 16 to 18V AC. 50 Hertz.
Battery Capacity: 12V 6.5 AH. Sealed Lead Acid Battery.
Battery Input Fuse: 5 Amperes.
Power Supply Output: Current: Total combined current required by devices connected to LAN “POS”
and “DET+” must not exceed 1.2 Amperes.
Fuse Protection: Separate 2 Ampere fuses provided for:
Siren1, Siren2, LAN Power & Detector Power.
ALWAYS REPLACE FUSES WITH THE SAME FUSE TYPE AND VALUE!
NOTE: See data supplied with detectors and output devices for actual current consumption of items connected to the module.
Mechanical Specifications
Dimensions: Length: 435 mm. Width: 320 mm. Depth: 112 mm.
Weight: 9.5 kg. (Includes mains transformer, battery and cover)

Inner Range 3000 Specifications

Power

power supply input voltage	11V to 14V DC
standby current consumption	25mA
logged on current consumption	35 to 40mA
lock relay active current consumption	60mA
all auxiliaries active current consumption	105mA
lock relay contacts voltage	30V DC maximum
lock relay contacts current	750mA maximum
fuse protection	500mA Reader Power Fuse

Operating Environment

module pcb temperature range	0º to 40º Celsius
module pcb humidity range	15% to 85% Relative humidity (non-condensing)
keypad temperature range	-20º to 70º Celsius
keypad moisture and dust rating	IP68

Weight and Dimensions

pcb length	96mm
pcb width	96mm
keypad height	130mm
keypad width	81mm
keypad depth	21mm
distance between mounting hole centres	82.2mm
mounting hole diameter	4.15mm
