Power| power supply input voltage | 11V to 14V DC |
|---|---|
| standby current consumption | 25mA |
| logged on current consumption | 35 to 40mA |
| lock relay active current consumption | 60mA |
| all auxiliaries active current consumption | 105mA |
| lock relay contacts voltage | 30V DC maximum |
| lock relay contacts current | 750mA maximum |
| fuse protection | 500mA Reader Power Fuse |
Operating Environment| module pcb temperature range | 0º to 40º Celsius |
|---|---|
| module pcb humidity range | 15% to 85% Relative humidity (non-condensing) |
| keypad temperature range | -20º to 70º Celsius |
| keypad moisture and dust rating | IP68 |
Weight and Dimensions| pcb length | 96mm |
|---|---|
| pcb width | 96mm |
| keypad height | 130mm |
| keypad width | 81mm |
| keypad depth | 21mm |
| distance between mounting hole centres | 82.2mm |
| mounting hole diameter | 4.15mm |
