MODEL 3000 / ACCESS 4000. CE Installation Notes.
8
LINKS. See pages 10 & 11 for location.
LK1 Telecom Country Selection. Removed: Europe TBR21 Fitted: Australia / New Zealand.
LK2 Memory chip (RAM) size select. 1-2 128k DS1245Y (32 Pin) or 512k DS1247Y (32 Pin)
2-3 32k DS1230Y (28 Pin)
LK3 Installer Code Default. Disconnect AC and Battery from Control Module; Short LK3 Pins; Reconnect power, then
remove the short. Installer code will be defaulted to “01”.
LK4 RAM Initialize. (“Continue”). Used when required to rectify Memory problems.
CAUTION! Will erase all programming if shorted to initialise memory.
LK6 Microprocessor select. Factory use only. Removed (Normal): Standard Micro. Fitted: Micro Type 1 or 2.
LK8 EPROM type selection. Factory use only. 1-2 Flash.
3-4 4 MBit EPROM.
5-6 2 MBit EPROM. See page 11 for diagrams.
LK9 EPROM configuration. Factory use only. 1-2 Flash.
2-3 EPROM.
LK10 LAN Termination. No Link. Unterminated. Link not fitted unless unit is first or last module on the LAN system.
Link IN. Terminated. Link fitted when unit IS the first or last module on the LAN system.
(See “LAN SYSTEM” details beginning on page 12 of this manual for more information)
LK12 PSTN / Direct Line selection.
LK13 Both links 1-2 PSTN (Dialler formats: IRfast, Contact ID, etc.)
Both links 2-3 Direct Line (e.g. EarthNet)
JP5 Regulated Power Supply Current Limit setting.
Not Shorted 1.0 Amp. Normal setting for 6.5 to 7.0 AmpHour Battery.
Shorted 3.0 Amp. Setting for 15 to 17 AmpHour Battery.
TERMINALS. See pages 10 & 11 for location.
T1-4 Zone Input connections. See Zone Input Wiring on page 6.
T5 LAN connections. See “LAN SYSTEM” details beginning on page 12 for details.
T6 Auxiliary outputs and Siren Outputs. See “SIREN WIRING” & “AUXILIARY WIRING” on page 7 for details.
T7 Battery connection.
T8 Detector Power. 12V Supply for Detectors and Auxiliary Devices.
Total current sourced from “DET+” and “LAN POS” must not exceed 1.2 Amps.
T9 16 to 18 V AC Input to PCB. (From Transformer Secondary winding)
T10 Tamper Switch Input. Tamper switch supplied. No End-of-line resistors necessary.
T11 Telecom connection Terminal block. Alternate connection for Dialer line or Direct line connection.
Pins 2 & 4: Line In. Connection to Exchange line or Leased line.
Pins 1 & 3: Line Out. Connection to other equipment sharing the Exchange line.
See drawings on page 6.

Inner Range 3000 Specifications

Power

power supply input voltage	11V to 14V DC
standby current consumption	25mA
logged on current consumption	35 to 40mA
lock relay active current consumption	60mA
all auxiliaries active current consumption	105mA
lock relay contacts voltage	30V DC maximum
lock relay contacts current	750mA maximum
fuse protection	500mA Reader Power Fuse

Operating Environment

module pcb temperature range	0º to 40º Celsius
module pcb humidity range	15% to 85% Relative humidity (non-condensing)
keypad temperature range	-20º to 70º Celsius
keypad moisture and dust rating	IP68

Weight and Dimensions

pcb length	96mm
pcb width	96mm
keypad height	130mm
keypad width	81mm
keypad depth	21mm
distance between mounting hole centres	82.2mm
mounting hole diameter	4.15mm
