Inner Range Inception Security Controller Installation Manual. Rev. 4.0

LAN and Reader Installation Diagrams.

The installation requirements are illustrated in the drawings below and on the following page.

The characters in square brackets reference the various points in the lists on the previous page.

LAN wiring detail

LAN network overview

[3]

[4]

[5]

[B]

[D]

[E]

[7]

[2]

[C]

[6] Shielded, twin, twisted-pair data cable
