Inner Range Inception Security Controller Installation Manual. Rev. 4.0
© 2016 - 2020. Inner Range Pty Ltd. 5 www.innerrange.com
System Capacities
Entity
Total
On-board Controller
With LAN Expansion
Areas
96†
Inputs
512
8
512
Outputs
512 #
4 *
512
Doors
128 # †
4 *
128
Lifts (V1.1.0 or later)
32
See V1.1.0 Release notes.
32
Lift Floors
512 #
4 *
512
SIFER Readers
256
8
256 (Up to 4 per SLAM)
Wiegand Readers
256 ‡
8 (Via 8 OSPD<>Wiegand Conv.)
254 ‡
Users
10,000 †
Events
250,000†
# Up to 512 Outputs can be programmed. Note that all types of ‘hardware outputs’ & ‘custom outputs’
count towards this total including door locks, DOTL, valid & invalid (for wiegand readers), lift floor
button enables, siren outputs, strobes, automation devices, etc.
* The Inception controller has 4 relay outputs in total. These can be used as lock relays for doors,
floor button enable contacts for lifts or general purpose dry contact outputs.
† Inception Firmware prior to V2.0.0 only supports 32 Doors and 2000 Users.
Inception Firmware prior to V3.1.1 only supports 50,000 Events.
Inception Firmware prior to V4.0 only supports 32 Areas.
‡ 256 Wiegand readers (In & Out Readers) requires a combination of up to 127 SLAMs (i.e. 1 per
door) and up to 8 OSDP<>Wiegand Converters.
Parts List
Main Parts
Inception Security Controller.
Installation manual (This document).
Inception Power Supply. 24V DC. 2.5A
Beginners Guide to Inner Range Systems.
IEC power cable. Right angle.
Inception Quickstart Guide
Accessory Kit (See below)
Inception User Manual
Accessory Kit contents
4 x Metal PCB Mounting Clip. M3.
3 x 2-way 5mm Screw Terminal.
4 x M3 x 25mm pan head screw.
4 x 3-way 5mm Screw Terminal.
4 x M3 brass spacer. 8mm.
3 x 4-way 5mm Screw Terminal.
Self-adhesive Hook & Loop tape, 50 x 25mm.
2 x 6-way 5mm Screw Terminal.
2 x Cable Ties 350 x 4.8mm.
2 x Female 6.3mm QC Connectors.
20 x 2k2 End-of-line Resistors.
Battery cable pair. 40cm. Red/Black.
4 x 1N4004 Diodes (for locks. *See note below)
Ethernet patch cable. 1m
NOTES:
* See “Output Relays (OUT1-4)” in the ‘WIRING DIAGRAMS’ section of this manual.

Inner Range inception Specifications

General

Model	Inception
Category	Controller
Users	10, 000
Event Log	50, 000 events
Power Supply	12-24V DC
Max. Readers/Doors	32
Max. Users	10, 000
Max. Areas	64
Onboard Inputs	8
Network	Ethernet
Onboard Outputs	4
Communication	Ethernet, RS-485
Operating Temperature	0°C to +50°C (32°F to 122°F)
