Introduction
Module Model and Nameplate
EtherCAT
communication
positioning
module
Nameplate
MODEL: AM600-4PME
POWER INPUT: 24 VDC 250 mA
OUTPUT: 24 VDC 0.5 A RES LOAD
VER: xxxxx
01022087YE400001
01022087YE400001
AM600-4PME
Product Information
AM
Inovance
medium-sized PLC
Automation-Motion
Series
600
600 series PLC
Channel
Count
4
4
channels
Module Type
Positioning
module
PM
Auxiliary Function
E
EtherCAT
communication
