Inovance MD021 - Unit Indicators, Digital Display, and Keys

MD021 Plastic Wire Drawing Machine User Manual
terminals or communication. When the indicator is off, it indicates
operation via operation panel. When the indicator is on, it indicates
operation via terminals. When the indicator blinks, it indicates
operation in the communication mode.
4.1.2 Description of the Unit Indicators
Hz: frequency unit
V: voltage unit
A: current unit
4.1.3 Digital Display
The 5-digit LED display is able to display operating frequency,
monitoring data and error codes.
4.1.4 Description of the Keys
Table 4-1 Functions of the keys
Key
Name
Function
PRG
Programming
key
Enter or exit Level I menu.
ENTER
Confirm key
Enter the menu interfaces
level by level, and confirm the
parameter setting.
▲
Increase key
Increase the value or function
code.
