MD021 Plastic Wire Drawing Machine User Manual
▼
Decrease key
Decrease the value or function
code.
►►
Shift key
Select the displayed
parameters in turn when the
inverter is in running or stop
state, and select the digit of a
parameter value to be
modified.
MFK
Not used.
QUICK
RUN
Run key
Press this key to run the
inverter in the operation panel
control mode.
STOP/RESET
Stop/Reset
key
Press this key to stop the
inverter in the running state
and reset the inverter in the
fault status.
4.2 How to Query and Modify Function Codes
The MD021’s operation panel adopts three-level menu, convenient for
quick querying and modification of parameters.
The three-level menu consists of function code group number (Level
I), function code (Level II), and function code value (Level III),
shown in Figure 4-2:
Figure 4-2 Three-level menu operation flowchart
